ER34-140/150

Nominal size NPS: ½ ~ 2

Connection: butt welding, flange
Nominal pressure Class: 1500 2500
Pressure difference range bar: 2 to 140 2 to 150
PMA/TMA bar/℃ : 140.9/500 153.7/538
Shell material: F22

Service Support Selection reference Hongfeng Classroom

Download ER34-140/150

Features

1.Equipped with a double valve seat differential pressure mechanism and SCCV closing system, ensuring reliable operation and high discharge capacity.

2.The valve features a water seal design, effectively preventing steam leakage.

3.The open float resists water hammer, and the top of the bucket is specially configured to prevent steam lock and air binding.

4.The valve seat is located at the top of the valve body. When the valve seat port opens, impurities are discharged from the body along with condensate under differential pressure.

5.The built-in check valve has some influence on discharge capacity.

6.Capable of withstanding high backpressure (up to 90%).

Application: Suitable for high‑pressure, superheated steam, and substantial condensate flow equipment.
